Manufacture Battery Equipment Intermittent Coating Machine Continuous Coating Equipment
The intermittent lab coating machine is a three-roll transfer coating equipment, which can be used for continuous and intermittent coating. It is convenient to be used in the surface coating process of various substrates. Especially in the lithium ion battery industry, the equipment is convenient for researchers to use, while meeting the requirements of coating accuracy and consistency is the same as the design of production, drying effect is excellent is lithium ion batteries, super capacitors, Ideal choice for nickel batteries and other secondary battery R & D and small trials.
Characteristic:
1. Can freely switch to realize continuous and intermittent coating;
2. Base material tension control, stable strike-band, and equipped with rectifying devices;
3. Hot-air oven, blowing on top and bottom, with good drying effect;
4. Three roll transfer coating with wider coating windows;
5. Comma scraper metering, with precision adjustment mechanism, to obtain high coating accuracy;
6. PLC control, touch screen operation, easy to use;
7. Alternative solvent recovery treatment units;
| No | Item | Data |
| 1 | Suitable system | Cathode and anode electrode coating process of Lithium Iron Phosphate, Lithium Cobalt, LiMnO4, etc. |
| 2 | Operating substrate thickness | Al: 11～30um Cu: 8～30um |
| 3 | Guaranteed coating width | Within 300mm |
| 4 | Equipment mechanical running speed | 1m/min |
| 5 | Equipment coating speed | 0.3m/min |
| 6 | Suitable viscosity of slurry | 2000~12000 Cps |
| 7 | Single side coating dry thickness range | 50-150μm |
| 8 | Minimum intermittent length | 5mm |
| 9 | Multistage minimum coating length | 20mm |
| 10 | Maximum roll diameter | Ф250mm |
| 11 | Doctor knife structure | Double-sided comma scraper |
| 12 | Oven structure | Single layer independent heating, upper and lower arrangement |
| 13 | Oven length | 1 m / block |
| 14 | Oven temperature | Design Max 120 ℃, temperature difference in single oven ≤ 5 ℃ |
| 15 | Mechanism | Rewinding and unwinding |
| 16 | Control system | Touch screen, PLC, module, servo system |
Our Services
We could supply one stop solution ( turn key project) for you.
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.
2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.
